SAE:5/8;  Flow cooling capacity(KW) under pressure drop△p(1 2)=0.22bar;   R36:29.2;  424A:29.2; R421C:28.5; Dimensions(mm):A:35;  B:110;  D:76; L:180;

ODF:5/8;  Flow cooling capacity(KW) under pressure drop△p(1 2)=0.07bar;  R134a:43.7;  R404A:36.9; R507:35.9; R22/R410A:53.8; R407C:50.9; Dimensions(mm)：A:24; B:189; D:76; L:237;

SAE:3/8;  Flow cooling capacity(KW) under pressure drop△p(1 2)=0.18bar;   R32:16.2;  420A:16.2; R417C:15.8; Dimensions(mm):A:27.5;  B:110;  D:76; L:165;

SAE:1/4;  Flow cooling capacity(KW) under pressure drop△p(1 2)=0.16bar;   R30:8.1;  418A:8.8; R415C:8.4; Dimensions(mm):A:22.5;  B:110;  D:76; L:155;

SAE:5/8;  Flow cooling capacity(KW) under pressure drop△p(1 2)=0.14bar;   R28:27.4;  416A:27.4; R413C:26.6; Dimensions(mm):A:35;  B:100;  D:63.5; L:170;

SAE:1/2;  Flow cooling capacity(KW) under pressure drop△p(1 2)=0.12bar;   R26:22.5;  414A:22.5; R411C:22.1; Dimensions(mm):A:30;  B:100;  D:63.5; L:160;

SAE:3/8;  Flow cooling capacity(KW) under pressure drop△p(1 2)=0.10bar;   R24:15.8;  412A:15.8; R409C:15.4; Dimensions(mm):A:27.5;  B:100;  D:63.5; L:155;

SAE:1/4;  Flow cooling capacity(KW) under pressure drop△p(1 2)=0.08bar;   R22:7;  410A:7; R407C:6.9; Dimensions(mm):A:22.5;  B:100;  D:63.5; L:145;

ODF:1-1/8;  Flow cooling capacity(KW) under pressure drop△p(1 2)=0.07bar;  R134a:95.3;  R404A:76.3; R507:74.1; R22/R410A:112.3; R407C:105.4; Dimensions(mm)：A:29; B:191; D:89; L:249;
