Temperature sensing element: NTC; Temperature control precision: +0.5°C; Temperature setting: 7-32°C; Display range: 7~32°C; Working condition: 5~35°C 0-90%RH; Key: Me chanical keys; Supply voltage: AC 18~30V 50/60HZ; Consumable Power: <1W; Terminal block: 2 lines*1.5 mm² ,or 1 line*2. 5mm² ; Load limitation: 1A with resistant load; 1. 5A with inductive load; Shell : Fire -retardant PMMA+ABS; Dimension: 118*88*30mm; Installation: 60mm or 83.5mm (standard); Protection : IP30; Mobile phone controland; Suitable for Android & IOS system;

5+2 programmable；Adjust filter usage counter；Battery power or 24V Hardwire；

5+2 programmable；6.8sq.inch backlight LCD；Battery power or 24V Hardwire；

100-240VAC；Easy for installation and applicable for twotwo-way valves or two three-way valves；5+2 weekly timer function；Optional for Celsius degree and Fahrenheit degree；

Supply Voltage: 85-260Vac,50/60Hz. Setpoint Range: 5 ~ 35°C. Setting Unit: 1°F or 0.5°C /step. Display Accuracy:土1°F or 0.5°C. Temperature Sensor: NTC Thermistor100K. Remote Controller(optional): Infrared Remote C ontrol. Mode Setting: Heating, Cooling and Ventilating. Fan Speed Adjust: High, Medium, Low and Automatic fan speed control. Cycling Fan Control: Fan cycled running with thermostat. Control Performance: ON/OFF control. Differential: 1°C/2°F. Thermostat Output: SPST relay for 2-pipe models, 2 SPST relay for 4-pipe models. Switch current rating: Resistive: 2A, Inductive: 1A. Environmental requirements: Operating temperature range 0 ~ 45°C, Humidity range 5 ~ 95 %RH (non-condensing).

Supply Voltage: 85-260Vac,50/60Hz. Setpoint Range: 5 ~ 35°C. Setting Unit: 1°F or 0.5°C /step. Display Accuracy:土1°F or 0.5°C. Temperature Sensor: NTC Thermistor100K. Remote Controller(optional): Infrared Remote C ontrol. Mode Setting: Heating, Cooling and Ventilating. Fan Speed Adjust: High, Medium, Low and Automatic fan speed control. Cycling Fan Control: Fan cycled running with thermostat. Control Performance: ON/OFF control. Differential: 1°C/2°F. Thermostat Output: SPST relay for 2-pipe models, 2 SPST relay for 4-pipe models. Switch current rating: Resistive: 2A, Inductive: 1A. Environmental requirements: Operating temperature range 0 ~ 45°C, Humidity range 5 ~ 95 %RH (non-condensing).

100-240VAC. Set points and room temperature display simultaneously.  6.8sq.inch backlight LCD. Compressor short cycling protection available.

Surface mounting. Cool, Heat and Vent. Digital LCD display. Blue backlight. Manual three-speed fan switch. Low temperature protection. Reliable output by relays. Fahrenheit or centigrade options.

Mode: Cool, Heat and Vent. Room Temperature setting. Detect and display room temperature. Low temperature protection. Manual/Auto fan speed change over. Backlight function available(optional). Remote control(Optional).
