Universal HVAC Surge Protective Device - Comprehensive Surge Protector, Watertight Enclosure

Model：SP50

A compact surge suppressor offering better surge protection levels.

50kA Maximum Surge Current, 120/240V AC Voltage Rating, 1-phase, 3-wire (isolated ground), NEMA 4X Enclosure Rating.

Add Inquiry Go Buy

Description

Product Specifications

2 Compressors Rack For Middle & High Temperature

Model			LTBBF2-18MY	LTBBF2-24MY	LTBBF2-28MY	LTBBF2-36MY	LTBBF2-46MY	LTBBF2-56MY	LTBBF2-68MY	LTBBF2-88MY
Temperature (°C)			-5°C~ +5°C
Refrigerant			R404A / R448A / R449A
Power Supply			380V/50Hz
Compressor	Type		Semi-hermetic
	Model		4TES-9Y	4PES-12Y	4NES-14Y	4HE-18Y	4GE-23Y	4FE-28Y	6GE-34Y	6FE-44Y
	Quantity		2	2	2	2	2	2	2	2
Capacity & Inpu	Evap-5°C	Capacity (KW)	48400	55200	65800	88400	102000	120400	150400	180600
	Evap-5°C	Input (KW)	20.36	22.58	27.26	36.78	44.0	51.6	65.4	77.8
	Evap-10°C	Capacity (KW)	38320	43600	52200	70800	82200	97200	121600	145800
	Evap-10°C	Input (KW)	18.56	20.54	24.96	33.78	40.2	47	60.2	72.0
	Evap-15°C	Capacity (KW)	29920	33700	40600	56000	65200	77600	97200	116400
	Evap-15°C	Input (KW)	16.64	18.34	22.46	30.6	36.42	43.4	54.8	65.8
Pipe	Suction Pipe (mm)		φ42	φ54	φ54	φ67	φ67	φ76	φ76	φ76
	Liquid Pipe (mm)		φ22	φ22	φ28	φ28	φ28	φ35	φ35	φ35
	Discharge Pipe (mm)		φ35	φ35	φ35	φ42	φ42	φ54	φ54	φ54
	Liquid in Pipe (mm)		φ28	φ28	φ28	φ35	φ35	φ42	φ42	φ42
Overall Dimension	*L (mm)W (mm)H (mm)*		195011201700	210011201700	210011201700	220011201700	220011201700	240011201700	240011201700	240011201700

Remarks: 1.Ambient Temp. 32C, condensing temp.45C.

3 Compressors Rack For Middle & High Temperature

Model			LTBBF3-27MY	LTBBF3-36MY	LTBBF3-42MY	LTBBF3-54MY	LTBBF3-69MY	LTBBF3-84MY	LTBBF3-102MY	LTBBF3-132MY
Temperature (°C)			-5°C~ +5°C
Refrigerant			R404A / R448A / R449A
Power Supply			380V/50Hz
Compressor	Type		Semi-hermetic
	Model		4TES-9Y	4PES-12Y	4NES-14Y	4HE-18Y	4GE-23Y	4FE-28Y	6GE-34Y	6FE-44Y
	Quantity		3	3	3	3	3	3	3	3
Capacity & Inpu	Evap-5°C	Capacity (KW)	72100	82900	98100	132600	152600	180000	221000	270200
	Evap-5°C	Input (KW)	30.5	33.9	40.9	55.2	66.0	78.0	98.1	116.7
	Evap-10°C	Capacity (KW)	57300	65400	78900	107300	123000	146300	181400	219200
	Evap-10°C	Input (KW)	27.8	30.8	37.4	50.7	60.3	72.0	90.3	108.0
	Evap-15°C	Capacity (KW)	44270	50400	60700	85300	96300	113600	142500	174780
	Evap-15°C	Input (KW)	25.0	27.5	33.7	45.9	54.6	65.8	82.2	98.7
Pipe	Suction Pipe (mm)		φ54	φ67	φ67	φ76	φ76	φ108	φ108	φ108
	Liquid Pipe (mm)		φ22	φ28	φ28	φ35	φ35	φ42	φ42	φ42
	Discharge Pipe (mm)		φ35	φ42	φ42	φ54	φ54	φ67	φ67	φ67
	Liquid in Pipe (mm)		φ28	φ35	φ35	φ42	φ42	φ54	φ54	φ54
Overall Dimension	*L (mm)W (mm)H (mm)*		275011201700	275011201700	275011201700	285011201850	285011201850	315011201850	315011201850	320011201850

Remarks: 1. All the above data calculated base on the condensing temperature 45C.

4 Compressors Rack For Middle & High Temperature

Model			LTBBF4-36MY	LTBBF4-48MY	LTBBF4-56MY	LTBBF4-72MY	LTBBF4-92MY	LTBBF4-112MY	LTBBF4-136MY	LTBBF4-176MY
Temperature (°C)			-5°C~ +5°C
Refrigerant			R404A / R448A / R449A
Power Supply			380V/50Hz
Compressor	Type		Semi-hermetic
	Model		4TES-9Y	4PES-12Y	4NES-14Y	4HE-18Y	4GE-23Y	4FE-28Y	6GE-34Y	6FE-44Y
	Quantity		4	4	4	4	4	4	4	4
Capacity & Inpu	Evap-5°C	Capacity(KW)	96800	113200	134800	180800	208800	259600	308000	369600
	Evap-5°C	Input (KW)	40.7	45.2	54.5	73.6	88.0	108.0	130.8	155.6
	Evap-10°C	Capacity (KW)	76400	87200	104200	141400	164000	194400	243200	291600
	Evap-10°C	Input (KW)	37.1	41.1	49.9	67.6	80.4	99.6	120.4	144.0
	Evap-15°C	Capacity (KW)	59360	67520	81600	110400	130400	154800	199200	230400
	Evap-15°C	Input (kW)	33.3	36.7	44.9	61.2	72.8	90.4	109.6	131.6
Pipe	Suction Pipe (mm)		φ54	φ67	φ76	φ76	φ108	φ108	φ108	φ133
	Liquid Pipe (mm)		φ28	φ28	φ35	φ35	φ42	φ42	φ42	φ42
	Discharge Pipe (mm)		φ42	φ54	φ54	φ54	φ67	φ67	φ67	φ79
	Liquid in Pipe (mm)		φ35	φ35	φ42	φ42	φ54	φ54	φ54	φ54
Overall Dimension	*L (mm)W (mm)H (mm)*		330011201700	330011201700	330011201700	350011201850	380011201850	380011201850	380011201850	380011201850

Remarks: 1. All the above data calculated base on the condensing temperature 45C.

2 Compressors Rack For Middle & Low Temperature

Model			LTBBF2-18LY	LTBBF2-28LY	LTBBF2-36LY	LTBBF2-46LY	LTBBF2-56LY	LTBBF2-68LY	LTBBF2-88LY
Temperature (°C)			-15°C~ -30°C
Refrigerant			R404A / R448A / R449A
Power Supply			380V/50Hz
Compressor	Type		Semi-hermetic
	Model		4TES-9Y	4NES-14Y	4HE-18Y	4GE-23Y	4FE-28Y	6GE-34Y	6FE-44Y
	Quantity		2	2	2	2	2	2	2
Capacity & Inpu	Evap-25°C	Capacity (KW)	17240	23400	33380	39340	47200	59400	70600
	Evap-25°C	Input (KW)	12.7	17.2	24.0	28.5	35.38	43.6	52.4
	Evap-30°C	Capacity (KW)	12600	17100	24900	29640	35580	45200	53200
	Evap-30°C	Input (KW)	10.8	14.5	20.7	24.7	30.4	37.9	45.4
	Evap-35°C	Capacity (KW)	8920	12060	18000	21740	25920	33360	38920
	Evap-35°C	Input (KW)	8.9	11.9	17.5	20.9	25.5	32.4	38.7
	Evap-45°C	Capacity (KW)	6000	8120	12440	15380	18140	23820	27220
	Evap-45°C	Input (KW)	7.2	9.4	14.5	17.4	20.8	27.1	32.1
Pipe	Suction Pipe (mm)		φ54	φ54	φ54	φ67	φ67	φ76	φ76
	Liquid Pipe (mm)		φ22	φ22	φ22	φ22	φ28	φ28	φ28
	Discharge Pipe (mm)		φ35	φ35	φ35	φ42	φ42	φ54	φ54
	Liquid in Pipe (mm)		φ28	φ28	φ28	φ28	φ35	φ35	φ35
Overall Dimension	*L (mm)W (mm)H (mm)*		210011201700	210011201700	210011201700	220011201700	240011201700	240011201700	240011201700

Remarks: 1. All the above data calculated base on the condensing temperature 45°C.

3 Compressors Rack For Middle & Low Temperature

Model			LTBBF3-27LY	LTBBF3-42LY	LTBBF3-54LY	LTBBF3-69LY	LTBBF3-84LY	LTBBF3-102LY	LTBBF3-132LY
Temperature (°C)			-15°C~ -30°C
Refrigerant			R448A / R449A
Power Supply			380V/50Hz
Compressor	Type		Semi-hermetic
	Model		4TES-9Y	4NES-14Y	4HE-18Y	4GE-23Y	4FE-28Y	6GE-34Y	6FE-44Y
	Quantity		3	3	3	3	3	3	3
Capacity & Inpu	Evap-25°C	Capacity (KW)	25860	35100	50070	59000	70800	89100	105900
	Evap-25°C	Input (KW)	19.1	25.7	36.0	42.8	53.07	65.4	78.6
	Evap-30°C	Capacity (KW)	18930	25650	37350	44460	53020	67800	79800
	Evap-30°C	Input (KW)	16.1	21.7	31.1	37.0	45.6	56.9	68.1
	Evap-35°C	Capacity (KW)	13380	18090	27000	32610	38780	50000	58380
	Evap-35°C	Capacity (KW)	13.4	17.8	26.3	31.4	38.25	48.6	58.1
	Evap-40°C	Capacity (KW)	9000	12180	18660	23070	27210	35700	40830
	Evap-40°C	Capacity (KW)	10.8	14.2	21.7	26.1	31.2	40.7	48.2
Pipe	Suction Pipe(mm)		54	54	67	76	76	108	108
	Liquid Pipe(mm)		22	22	28	28	28	35	35
	Discharge Pipe(mm)		42	42	42	42	54	54	67
	Liquid Pipe(mm)		28	28	35	35	35	42	42
Overall Dimension	*L (mm)W (mm)H (mm)*		275011201700	275011201700	2750	285011201700	315011201850	315011201850	315011201850

Remarks: 1. All the above data calculated base on the condensing temperature 45°C.

4 Compressors Rack For Middle & Low Temperature

Model			LTBBF4-36LY	LTBBF4-56LY	LTBBF4-72LY	LTBBF4-92LY	LTBBF4-112LY	LTBBF4-136LY	LTBBF4-176LY
Temperature (°C)			-15°C~ -30°C
Refrigerant			R404A / R448A / R449A
Power Supply			380V/50Hz
Compressor	Type		Semi-hermetic
	Model		4TES-9Y	4NES-14Y	4HE-18Y	4GE-23Y	4FE-28Y	6GE-34Y	6FE-44Y
	Quantity		4	4	4	4	4	4	4
Capacity & Inpu	Evap-25°C	Capacity (KW)	34480	46800	66760	78680	94400	118800	141200
	Evap-25°C	Input (KW)	25.4	34.3	48.0	57.1	70.76	87.2	104.8
	Evap-30°C	Capacity (KW)	25240	34200	49800	59280	71360	90400	106400
	Evap-30°C	Input (KW)	21.5	29.0	41.4	49.3	60.8	75.8	90.8
	Evap-35°C	Capacity (KW)	17840	24120	36000	43480	52040	66720	77840
	Evap-35°C	Capacity (KW)	17.8	23.8	35.0	41.8	51.0	64.8	77.4
	Evap-40°C	Capacity (KW)	12000	16240	24880	30760	36280	47640	54440
	Evap-40°C	Capacity (KW)	14.4	18.9	28.9	34.8	41.6	54.2	64.3
Pipe	Suction Pipe(mm)		54	54	67	76	108	108	108
	Liquid Pipe(mm)		22	22	28	28	35	35	35
	Discharge Pipe(mm)		42	42	54	54	54	67	67
	Liquid Pipe(mm)		28	28	35	35	42	42	42
Overall Dimension	*L (mm)W (mm)H (mm)*		330011201700	330011201700	350011201700	350011201700	380011201850	380011201850	380011201850

Remarks: 1. All the above data calculated base on the condensing temperature 45°C.
