SAE:3/8; Flow cooling capacity(KW) under pressure drop△p(1 2)=0.07bar; R134a:12.9; R22/R410A:14.1; R407C:13; R404A/R507:9.5; R502:9.1; Dimensions(mm)：A:27.5; B:76; D:63.5; L:131;

ODF:3/8; Flow cooling capacity(KW) under pressure drop△p(1 2)=0.07bar; R134a:10.5; R22/R410A:11.6; R407C:11.6; R404A/R507:7.7; R502:.7.4; Dimensions(mm)：A:19; B:66; D:42; L:104;

ODF:3/8; Flow cooling capacity(KW) under pressure drop△p(1 2)=0.07bar; R134a:10.5; R22/R410A:11.6; R407C:11.6; R404A/R507:7.7; R502:.7.4; Dimensions(mm)：A:19; B:66; D:42; L:104;

ODF:1/4; Flow cooling capacity(KW) under pressure drop△p(1 2)=0.07bar; R134a:8.1; R22/R410A:8.8; R407C:8.5; R404A/R507:6; R502:5.6; Dimensions(mm)：A:16.5; B:66; D:42; L:99;

SAE:3/8; Flow cooling capacity(KW) under pressure drop△p(1 2)=0.07bar; R134a:9.5; R22/R410A:10.2; R407C:10.2; R404A/R507:7; R502:6.7; Dimensions(mm)：A:27.5; B:66; D:42; L:121;

SAE:1/4; Flow cooling capacity(KW) under pressure drop△p(1 2)=0.07bar; R134a:6.7; R22/R410A:7.4; R407C:7; R404A/R507:5; R502:4.6; Dimensions(mm)：A:22.5; B:66; D:42; L:111;

ODF:1-1/8;  Flow cooling capacity(KW) under pressure drop△p(1 2)=0.36bar;   R50:68.9;  438A:68.9; R435C:67.8; Dimensions(mm):A:29;  B:181;  D:76; L:239;

ODF: 7/8;  Flow cooling capacity(KW) under pressure drop△p(1 2)=0.35bar;   R49:58.8;  437A:58.8; R434C:57.7; Dimensions(mm):A:28.5;  B:181;  D:76; L:238;

ODF:3/4;  Flow cooling capacity(KW) under pressure drop△p(1 2)=0.34bar;   R48:56.3;  436A:56.3; R433C:55.3; Dimensions(mm):A:26;  B:181;  D:76; L:233;
