SAE:3/8;  Flow cooling capacity(KW) under pressure drop△p(1 2)=0.07bar;  R134a:12.9;  R404A:9.9; R507:9.6; R22/R410A:14.5; R407C:13.8; Dimensions(mm)：A:27.5; B:66; D:43; L:121;

SAE:1/4;  Flow cooling capacity(KW) under pressure drop△p(1 2)=0.07bar;  R134a:6.7;  R404A:5.1; R507:4.9; R22/R410A:7.5; R407C:7.1; Dimensions(mm)：A:22.5; B:66; D:43; L:111;

ODF:1-1/8;Flow cooling capacity(KW) under pressure drop△p(1 2)=0.07bar;R134a:115.1;R22/R410A:124.6;R407C:122.5;R404A/R507:83.4;R502:80.9;Dimensions(mm)：A:29;B:343;D:89;L:401;

ODF:7/8;Flow cooling capacity(KW) under pressure drop△p(1 2)=0.07bar;R134a:78.1;R22/R410A：84.8;R407C：83.1;R404A/R507：56.7;R502：54.9;Dimensions(mm)：A:28.5;B:343;D:89;L:400;

ODF:1-1/8;Flow cooling capacity(KW) under pressure drop△p(1 2)=0.07bar;R134a:97.5;R22/R410A：105.6;R407C：103.4;R404A/R507：70.8;R502：68.6;Dimensions(mm)：A:29;B:191;D:89;L:252;

ODF:7/8;Flow cooling capacity(KW) under pressure drop△p(1 2)=0.07bar;R134a:71.5;R22/R410A：77.0 ;R407C：76;R404A/R507：51.7;R502：50.3;Dimensions(mm)：A:28.5;B:191;D:89;L:251;

ODF:3/4;Flow cooling capacity(KW) under pressure drop△p(1 2)=0.07bar;R134a:63.8;R22/R410A：70.2;R407C：69.6;R404A/R507：48.6;R502：47.8;Dimensions(mm)：A:26;B:191;D:89;L:246;

ODF:7/8;Flow cooling capacity(KW) under pressure drop△p(1 2)=0.07bar;R134a:59.1;R22/R410A：64;R407C：63.0 ;R404A/R507：42.9;R502：41.5;Dimensions(mm)：A:28.5;B:191;D:76;L:249;

ODF:3/4；Flow cooling capacity(KW) under pressure drop△p(1 2)=0.07bar; R134a:52.1； R22/R410A：56.3; R407C：55.3; R404A/R507：37.6； R502：36.6； Dimensions(mm)：A:26; B:191; D:76; L:248;
